SWE-Eurodrive GmbH & Co. KG, a German family-owned company operating in the area of drive technology, expands its plant until 2019 at Graben-Neudorf. The existing plant with a size of 1,184,030 ft² will almost be doubled. The main components of the extension is a factory building, a combined pedestrian and media bridge as well as a road bridge.
The planning of the whole project was carried out according to the BIM method. A digital entire structure has been already created in the design phase which has been specified in detail during further planning.
The engineering office Grassl GmbH from Stuttgart was responsible for the structural design. They created the supporting structure in Revit and Tekla Structures and used the direct interfaces to RFEM to perform the structural analysis there. Cross-section modifications from structural analysis were transferred back to Revit and Tekla Structures and updated at the building model.
