Webinar 2: Advanced modeling features in RFEM
Free Online Webinar
- Buckling behavior of members utilizing RF‑STABILITY
- Use of "line releases" for the connection of beam to surface
- Addressing FEA singularities with concrete surface design
- Nonlinear material modeling with a plastic stress analysis of a steel connection
- Up to 00:02:17: Introduction
- Up to 00:13:18: Addressing instabilities with RF-STABILITY
- Up to 00:21:02: Use of "line releases" for beam to slab interaction
- Up to 00:24:40: Use of "sections" for surface results
- Up to 00:27:20: Use of the "clipping plane" for surface/solid results
- Up to 00:39:53: Addressing FEA singularities with "average regions"
- Up to 00:58:54: Nonlinear plastic analysis of FEA connection with RF-MAT NL
- Up to 01:01:35: Conclusion
