Masonry Wall Design in RFEM 6
Free Webinar Information
Everything I Expected and More
"RFEM is everything I expected and more. I’m having a blast learning the software and the webinars are fantastic."
Nicholas J. Greven P.Eng.
23 July 2019
In this webinar, we show you how to model walls made of masonry in RFEM 6 and how to design them using the Finite Element Analysis (FEA).
Recorded Webinar
Date | Time
Event Language
EnglishTime Schedule
| 0:00 | Introduction |
| 3:00 | Material properties and determination of Young's modulus E for masonry |
| 16:25 | Determining internal forces and moments of masonry elements predominantly subjected to vertical loading using isotropic material model |
| 35:50 | Shear wall (with and without opening) using orthotropic material model |
Below, under Models to Download, you will find the model(s) used in the webinar. This will allow you to independently follow the webinar step by step with the provided model(s) after the presentation is complete.
Speakers
Dipl.-Ing. (FH) Andreas Hörold
Marketing & Public Relations
Mr. Hörold takes care of the Dlubal Software website, creates press releases as well as marketing materials, and is the moderator of the German and English webinars.
Dipl.-Ing. (FH) Ulrich Lex
Product Engineering & Customer Support
Dipl.-Ing. Frank Faulstich
Product Engineering & Customer Support
Mr. Faulstich is responsible for the quality assurance of the RFEM program, and also provides customer support.
Keywords
Free Webinar RFEM 6 Masonry Finite Element Analysis FEA Orthotropic Material Model
