In the model, there are two governing internal forces, V z and M y . In the printout report selection, I have only activated these two internal forces with the "Extreme values" option. Why are duplicate result rows displayed in the report under "Members - Internal Forces"?

Answer

The reason for four result rows (see Figure 01) in this case is that a minimum and a maximum including the corresponding remaining internal forces are displayed for each selected internal force.

Figure 01 - Printout report: Members - Internal Forces

  • First row: numerical maximum of V z (3.54 kN) with corresponding internal forces
  • Second row: numerical minimum of V z (0 kN) with the corresponding internal forces
  • Third row: numerical maximum of M y (0 kNm) with corresponding internal forces
  • Fourth row: numerical minimum of M y (-12.37 kNm) with corresponding internal forces

Keywords

Printout report Internal forces Result rows Double Triple Multiple
