The pedestrian bridge over the Taffa river functions not only as a bridge, but also includes a garden tool shed and seating along the platform. Additionally, the delicate top truss chords provide pedestrian railing along the bridge length.
The Austrian Steel Construction Award 2019 was presented to both the structural engineering firm KonstruktING GmbH and the architecture firm 4juu architekten for their collaborated design of the project.
The pedestrian bridge has a total length of 22.70 m with a free span of 15.34 m. The top and bottom truss chords consist of solid steel bars. The truss web members areround steel bars arranged between the chords at varying angles and spacing. The round bars are arranged in four planes which increase the transverse stiffness.
A thin deck of flat bars and channel sections spans between the bottom chords. The hardwood plank flooring is further placed on top of the deck. The pedestrian bridge widens as a Y-shape at the garden entrance. The garden tool shed is integrated at this location.
Architect:
4juu architekten, Horn, Austria | www.4juu.at
Structural Analysis:
Konstrukt:ING GmbH, Vienna, Austria | www.konstruktING.at
Steel Structure:
Johann Binder, Gföhl, Austria | www.schlosserei-binder.at
Photos and model:
© by 4juu architekten
© by Konstrukt: ING GmbH
