Display Settings RSTAB RFEM

How can I change the scale for the graphical representation of member loads or the distance of the load from the member axis?

Answer

You can change the graphical representation of loads in the display properties.

To do this, right-click the load that you want to change, and then select Display Properties in the context menu. Now you can change the settings for the selected object directly.

To go to the display properties directly, select DisplayProperties in the Options menu.

Keywords

Display Properties Load distance Distance load Display of load
