- This online training provides solutions to your current design projects.
- Our qualified training instructors have the necessary expertise and experience.
- Gain valuable program insight for increased company efficiency and decreased overhead costs.
- You have no additional costs for travel, accommodation, etc.
Eurocode 2 | Concrete structures according to DIN EN 1992-1-1
Information about online training
Why Attend the Online Training?
Online group training sessions provide the opportunity to gain expert knowledge and to ensure you’re getting the most out of your Dlubal programs.
Date | Time
Event Language
EnglishContent
Online training on reinforced concrete design according to DIN EN 1992-1-1
In this training, the verification of reinforced concrete structures according to the DIN EN 1992-1-1 standard is explained by means of the structural analysis software RFEM and the relevant add-on modules.
The application of the additional modules for dimensioning according to EC 2 will be explained using selected practical examples. The ultimate limit state load capacity (ULS), serviceability (ULS), stability analysis and punching-through are themes which are dealt with.
Price
195.00 EUR net, excluding VATTime Schedule
| - |
Basic information
|
| - |
Combinatorics
|
| - |
Basics of the design in RF-CONCRETE Members
|
| - |
Basics of design in RF-CONCRETE Surfaces
|
| - |
Punching shear checks with RF-PUNCH Pro
|
| - |
Serviceability
|
| - |
Stability Analysis
|
| - | Tips & Tricks |
Additional information
A reliable internet connection is required to participate. Basic knowledge in the use of RSTAB or RFEM is also required. The online training is carried out using RFEM with the associated add-on modules.
During the training, each participant can ask questions via chat at any time.
Each participant receives after the event
- Training certificate
- Training presentation for download
- Used models for download
- Video recording of the training
This allows the participant to go through or understand the training independently step by step by means of the presented models.
In order to take part in the online training, the participant will receive the login information in time.
Speakers
Dipl.-Ing. (FH) Adrian Langhammer
Product Engineering & Customer Support
Mr. Langhammer is responsible for the development of the add-on modules for reinforced cocrete, and provides technical support for our customers.
Dipl.-Ing. (FH) Paul Kieloch
Product Engineering & Customer Support
As technical support, Mr. Kieloch answers the questions of Dlubal Software customers, and is responsible for the development of the add-on modules for reinforced concrete structures.
Keywords
Online training Reinforced concrete design Eurocode 2 EC 2 Load capacity Serviceability Deformation calculation Non-linear calculation Determination of crack width Punching through
Links
- Concrete Structural Analysis & Design Software
- Link 2
- Product Description | RFEM add-on module RF-CONCRETE Deflect
