Membrane Structures with Wind Loads From CFD Wind Simulation
Information about the Free Webinar
★
★
★
★
★
Everything I Expected and More
"RFEM is everything I expected and more. I’m having a blast learning the software and the webinars are fantastic."
Nicholas J. Greven P.Eng.
23 July 2019
This webinar demonstrates how wind loads can be determined in RFEM for membrane structures by means of CFD wind simulations.
Date | Time
Event Language
EnglishContent
Webinar | Membrane Structures with Wind Loads From CFD Wind Simulation
Time Schedule
| 00:00 | Introduction |
| 04:00 | Modeling of a grandstand roof including loads (self-weight, snow) |
| 46:40 | Wind load generation based on CFD |
| 55:00 | Combination of loads |
| 1:03:20 | Stability analysis in RF-STABILITY |
| 1:07:20 | Member design in RF-STEEL EC3 |
| 1:10:10 | Consideration of additional objects that have an influence on the wind flow |
Presentation Model to Download
Below, under Models to Download, you will find the model(s) used in the webinar. This will allow you to independently follow the webinar step by step with the provided model after the presentation is complete.Keywords
Free online webinar Tensile Fabric Cable Form-finding CFD Wind Stability Steel Temporary structure
