FAQ 004230 EN
Are the Dlubal Software programs applicable for analysis of process manufacturing plants?
Answer
Main Programs RFEM or RSTAB
- RF-/STEEL
Calculation of stresses and comparison with limit stresses - RF-PIPING
Modeling of pipelines (in RFEM only) - RF-PIPING Design
Design of pipelines (in RFEM only)
Dynamic Analysis
Keywords
Industry Plant Plant engineering Process manufacturing plant Chemical Petrochemical Pharmaceutical Hall Production hall Container Filter Boiler Scaffolding Noise protection Conveyor belt
