SHAPE-THIN determines the effective cross-sections according to EN 1993-1-3 and EN 1993-1-5 for cold-formed sections. You can optionally check the geometric conditions for the applicability of the standard specified in EN 1993‑1‑3, Section 5.2.
The effects of local plate buckling are considered according to the method of reduced widths and the possible buckling of stiffeners (instability) is considered for stiffened sections according to EN 1993-1-3, Section 5.5.
As an option, you can perform an iterative calculation to optimize the effective cross-section.
You can display the effective cross-sections graphically.
Read more about designing cold-formed sections with SHAPE-THIN and RF-/STEEL Cold-Formed Sections in this technical article: Design of a Thin-Walled, Cold-Formed C-Section According to EN 1993-1-3.
- After calculating the cross-section data, an ellipse is displayed in the cross-section. In addition to the coordinate system, there are wide lines displayed above the x- and y-axis. Which displays are we talking about here? How can I deactivate it?
- I cannot manage to correctly import the cross-section from a dxf file into the SHAPE‑THIN program, the imported cross-section is in a wrong plane. What can I do?
- In which drawing plane must a cross-section be drawn in a CAD application so that it can be imported into SHAPE‑THIN using the dxf import?
- The installation of a Dlubal Software program is not possible due to the following message: "Program unsafe, protection by Microsoft Defender SmartScreen." How can I install the program?
- I get the following message when starting all installed Dlubal programs (also when running as administrator): "The application was unable to start correctly (0xc0150002)." What can I do?
- In SHAPE‑THIN, I get the error message saying that the material library cannot be opened. I have reinstalled the program and integrated the material library of another computer, but without any success. What should I do?
- The calculation of a file runs smoothly for my colleagues, but I get the message "Calculation stopped" for the same file. What should I do?
- When starting the Dlubal Software programs, the error message "Server is busy" appears. My colleagues do not experience this problem. I have already tried to reinstall. What should I do?
- What is the purpose of a fillet weld in SHAPE‑THIN?
- How can I display shear stresses on null elements in SHAPE‑THIN?
