Online Manual RFEM | Surfaces
Folded plate structures | Pyramidal folded plate with vertical stiffener | Rectangular floor plan
FPC001 | Pyramid Roof with Jamb Walls
No Download Possible
Customer Project / for View Only
| Block parameters editable dynamically | |
| Number of Nodes | 9 |
| Number of Lines | 16 |
| Number of Members | 0 |
| Number of Surfaces | 8 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 14.817 tons |
| Dimensions | 13.12 x 13.12 x 13.12 feet |
