What is the way for displaying a load-deformation diagram for any node of the structure?


A load-deformation diagram for any node of a model (Figure 1) can be defined as a user-defined calculation diagram within the calculation parameters (button or menu 'Calculation' → 'Calculation Parameters') and displayed with the corresponding results:

  • To set the desired load increments within the global calculation parameters, see Figure 2

  • Definition of a user-defined calculation diagram within the 'Calculation Diagrams' tab: For the selection of the load case, the corresponding node, and the result types of the horizontal and vertical axis see Figure 3


Load-deformation diagram Load-deformation diagram Diagram Calculation Diagram
