Answer:
Shortcuts are not displayed in Visibility by default. However, when you create your own visibility, you can set the display of the shortcuts there.
Visibility - Shortcuts
When activating Visibility in the Views navigator, I cannot see or use the shortcuts, although they are active. Why?
