Select the Action Combinations tab.
There are eleven combinations listed. However, only two action combinations are marked as active, 'AC1' and 'AC3'. These are the controlling combinations determined by the program. The users may activate the other combinations, if needed. The load factors are assigned according to the selected specification, which you can check on the 'Assignment' subtab again.
