Hybrid Structure System | Superposition System | Superposition of section-active and form-active structure systems | Cable supported beam grid | Bottom chord is a parabola
HSS004 | Hybrid Structure System
| Block parameters editable dynamically | |
| Number of Nodes | 68 |
| Number of Lines | 108 |
| Number of Members | 104 |
| Number of Surfaces | 1 |
| Number of Solids | 0 |
| Number of Load Cases | 1 |
| Number of Load Combinations | 0 |
| Number of Result Combinations | 0 |
| Total Weight | 214.298 tons |
| Dimensions | 59.06 x 19.69 x 59.06 feet |
