How can I simulate buildings with window openings as a closed unit in RWIND Simulation?

Answer

Potential window, door and facade openings can be included in RWIND Simulation by using the model simplification (shrink-wrapping mesh) for the wind flow analysis. This meshing option "refines" the imported models against the wind flow entering the model with the accompanying internal pressure load. To determine which opening should be closed and which openings should remain open, the program uses the size specification. Thus, all openings with the dimensions smaller than the specified control dimension will be closed generically for the wind flow analysis in the numerical wind tunnel.


Figure 01 - Velocity Distribution for Closed and Open Building Structure

In RWIND Simulation, you can specify the opening size in the "Edit Model" menu of the respective models.

Figure 02 - Specifying Openings in RWIND Simulation

The RFEM or RSTAB interface menu includes the opening size specification for the automatic calculation of wind loads in the background in the "Simulate and Generate Wind Loads" dialog box under the "Wind Load" tab.

Figure 02 - Specifying Openings in RWIND Simulation

In order to simulate a closed building structure, it is also possible to consider additional surfaces in the opening areas by using an STL import or directly using a load distribution surface in RFEM.
