Question:
Is it possible to display or export certain results over a period of time from the time history calculation in RF‑DYNAM Pro - Forced Vibrations?
Answer:
With a time course monitor, you can view all results over a period of time. In this case, it is also possible to select several parts of the structure and then export the results directly to Excel.
