How can I insert an average region/an average line in the result diagram?

Answer

In the Result Diagrams dialog box, it is possible to create average regions to prepare the results for engineering. This function is available with the 'Edit Average Regions' button. The dialog box in Figure 1 opens.

Define the average regions in the table columns on the left; entries for Start, End, and Length are interdependent. Each region can be activated separately. The 'Use for Results' section controls for which deformations, internal forces, stresses, or strains a smoothing is to be performed. The smoothing can be constant or linear for all average regions.

Furthermore, an average line can be displayed over the entire result diagram via the button of the same name (Figure 2).

The integral of the average region is displayed if the 'With Result Interpretations' checkbox is selected in the settings of the result diagrams (Figure 3).
