Interfaces with RFEM 6 Briefly Presented: DXF, IFC, Autodesk Revit
Why a webinar? There's a simple answer: Webinars provide the opportunity to gain expert knowledge and to ensure you’re getting the most out of your Dlubal programs.
This webinar shows how to exchange data with RFEM 6 / RSTAB 9 via DXF, IFC, or Autodesk Revit.
Do you have any question about the topic of the presentation? Send us your questions up to two days in advance. If possible, we will answer them during the webinar.
Even after the webinar, you can easily repeat the content. Below, under Models to Download, you will find the model(s) used in the webinar. This will allow you to independently follow the webinar step by step with the provided model after the presentation is complete.
Additionally, each participant will receive a certificate indicating the name provided during the registration.
Refresh your knowledge! Below, under Models to Download, you will find the model(s) used in the webinar. This will allow you to independently follow the webinar step by step with the provided model after the presentation is complete.
Abdulrzzak Ali, M.Sc.
Public Relations & Marketing
Mr. Ali is responsible for Arabic marketing and creating video content, as well as conducting webinars and training courses.
Doğukan Karataş, M.Sc.
Product Engineering
Mr. Karataş is responsible for the development and quality assurance of Dlubal programs.
