Concrete Design | Columns | Design/Results

Do you want to perform the bending failure design? To do this, analyze the governing locations of the column for axial forces and moments. For the shear resistance design, you can also consider the locations with extreme values of shear forces. During the calculation, you determine whether a standard design is sufficient or whether the column with the moments has to be designed according to the second-order theory. You can then determine these moments using the previously entered specifications. The calculation is divided into three parts:

Load-independent calculation steps
Iterative determination of governing loading taking into account a varying required reinforcement
Safety determination of all acting internal forces, including the designed reinforcement

After a successful calculation, the results are displayed in clearly arranged tables. Each intermediate value is absolutely traceable, making the design checks transparent.

Cross-Section Design Ratios of Columns
