When calculating data in RF-CONCRETE Members, I receive the warning "Error while reading the internal forces by main program!", although results are available. What is the reason?


In RF-CONCRETE Members, you can design result beams. If the result beams to be designed are defined incorrectly so that no internal forces can be determined for them, a warning message appears when designing in RF-CONCRETE Members. The result beams that have been defined incorrectly can be found by displaying the output of member internal forces. These result beams must be modified accordingly.
In this example, there is no output for internal forces related to the result beam 2. Instead of surface 2, surface 1 was mistakenly specified as the included object for this result beam (Figure 2).


Warning No. 374 Warning message Error Calculation Result beam
