The FEA software RFEM allows for the modeling and structural analysis of general plate, shell, and member structures. It is also possible to analyze combined structures as well as solid elements and objects with contact properties.
This user manual describes the modeling, calculation, and result evaluation features related to the structural analysis.
Product Feature
Product Feature
Product Feature
Use the "Independent mesh preferred" option in the FE mesh settings to create an independent FE mesh for the integrated objects. This allows you to generate a significantly more detailed and precise FE mesh for individual objects that are integrated into one another.
In the "Edit Section" dialog box, you can display the buckling shapes of the Finite Strip Method (FSM) as a 3D graphic.
In RFEM 6 and RSTAB 9, you have the option to enter "Visual Objects" as guide objects. You can import the file formats 3ds, stl, and obj.
These objects allow you to create a better reference to the dimensions.
