With a line set, you can combine lines and classify them as a unit. This way it is possible, for example, to assign a trapezoidal load over all lines or to group curved lines appropriately.
Line Set Type
The line set type describes the way lines are grouped. Two types are available for selection in the list.
Continuous Lines
Continuous lines are formed by connected, continuous lines. The end node of one line represents the start node of the next line. You can imagine drawing continuous lines without lifting your pen.
Group of Lines
A group of lines consists of connected lines that may branch.
Lines Nos.
Enter the numbers of the lines, or select them in the work window by using the button. Use the button to reverse the order of line numbers so that the direction of the line set is changed.
